Cayin CS-100CD CD player
Music has the ability to move us, and take us somewhere new - this experience exists in the subtle details and nuances of the music itself.
As the music unfolds, the presentation of the unique colours, textures, intonations and expressions that intertwine, create something that truly inspires us.
Cayin Audio have gone to significant lengths to bring to market a CD player that embodies this utopian ideal.
Through amazing attention to detail and meticulous and inspirational bespoke engineering, Cayin Audio create the sublime CS-100CD that reproduces music with authenticity, authority and emotion.
Take your listening experience to a whole new level, and allow the CS-100CD to reveal the true depth and essence of the recording as the artist intended.
Features
| Model | CS-100CD |
| Output Level | 2.3V +/- 2dB |
| Frequency Response | 20Hz20kHz±0.5dB |
| Dynamic Range | 110dB |
| Channel separation(1kHz) | 80dB |
| Power consumption | <40w |
| S/N Ratio | 100dB |
| Distortion and noise | -60dB |
| Dimension | 440mm×392mm×126mm(W×D×H) |
| Net Weight | 12kg |
| CD PLAYER | Support CDCD-R16-bit 44.1kHz |
| Digital Input | |
| Optical input | 16/24-bit 44.1-192kHz |
| Coaxial input | 0.5V @7516/24-bit 44.1-192kHz |
| USB Audio (only for USB version) | Compatible with Audio Class 1.0 and Audio Class 2.0. Support Windows XP®Windows Vista®Windows 7® Windows 8® and Mac OS(10.6.3 and above) |
| Digital Output | |
| Optical output: | 16/24-bit 44.1-192kHz. According to the IEC958 standard |
| Coaxial output | 0.5V @75 16/24-bit 44.1-192kHz According to the IEC958 standard. |
| AES/EBU output | 11016/24-bit 44.1-192kHzAccording to the IEC958 standard. |
- Incorporates two PCM1792A DAC chip sets from Texas Instruments, for digital filtering and D/A conversion - this is configured into a fully balanced design for the output circuit.
- Deploys dedicated, high quality Op-Amps for Low pass Filter circuit and I/V converter circuits.
- Deploys four x 6922EH vacuum tubes and exquisite audio grade capacitors for the audio output.
- Entirely separate tube circuits for both the Balanced and Unbalanced outputs.
- Deploys one 12DT5 for tube regulation so this results in a very high quality power supply for the tube audio circuits.
- Versatile digital outputs where you can select between Optical, Coaxial or AES/EBU digital outputs.
- Deploys USB Audio, Optical, Coaxial or AES/EBU for different input source selection.
- Supports both Coaxial and Optical digital inputs and will process up to 24 bit/192 kHz.
- Employs a state of the art, high resolution USB Audio technology, and will accept and decode Hi-res digital audio through USB interface and supports up to 24 bit/192kHz.
- Independent power supplies are employed to feed the digital circuit and analogue circuits. This reduces the power interference among the different circuit topologies and makes sure all components will have the optimum/clean power all the times.
